Impulse Plastic Bag Sealer Hand Film Sealing Machine PFS-300
Product Details
Make and Sale Hand Impulse Plastic Bag Sealer PFS-300 Table Top Make 300 mm / 12 inches / 30 cm Wide Heat Press Plastic Film Bag Sealing Machine By Zhejiang Tianyu Industry Co.,Ltd. Supplier Factory Manufacturer In China,Hand Impulse Plastic Bag Sealer ABS Plastic Shell PFS-Series Table Top Make Heat Press Plastic Film Bag Sealing Machine can be placed on table or wall-mounted for vertical sealing. This unique ABS Plastic Shell portable impulse sealer makes it possible to seal bags rapidly while holding the bag with two hands. To activate the sealer the user just needs to depress the work table. That's why this is called a "press sealer" because you press the table to seal the bag. This versatile sealer allows the user to package more products efficiently and quickly.This sealer suits for various plastic films package, which applies to foodstuff, candy, medicine. The local specialty, electric elements, etc. It is can use in factories, shops and service industries as well. For PE/PP Bags Impulse sealing for power sealing Precision Electronic Control Circuit.
Width for seal: 2mm
Max.thickness for seal: 0.8mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Can Make OEM Products
Packaging Type: Bags, Film
Packaging Material: Plastic
Type: Sealing Machine
Application: Commodity, Food, Machinery & Hardware, Medical
Automatic Grade: Manual
Driven Type: Electric
ABS Plastic Shell
Non-toxic environment-friendly super durable
Without preheating,power-and-go
Easy operation, more effective and time-saving
Automatic power off after sealing
SAA approval plug: EU plug/AU plug
CE certified
Hand Impulse Plastic Bag Sealer PFS-300 Table Top Make 300 mm / 12 inches / 30 cm Wide Heat Press Plastic Film Bag Sealing Machine Description:
Model: PFS-300
Color: Light Blue,Green,White or Red Shell
Power:400W
Source: 110V/60Hz or 220V/50Hz
Power: 400W
Dimension: 430X102X175mm (L X W X H)
Item Weight: 1.68 kg
Sealing Length: 300mm
Max Sealing Width: 2mm
Sealing Thickness: 0.01-0.8mm
Heating time:0.2-1.5S
This plastic sealer machine does not require pre heating, you can just put the plug ac power socket and adjust the heating time according to the thickness of the material to be sealed.
Hand Impulse Plastic Bag Sealer PFS-300 Table Top Make 300 mm / 12 inches / 30 cm Wide Heat Press Plastic Film Bag Sealing Machine Package Included:
1 x PFS-300 Hand Impulse Plastic Bag Sealer
2 x Extra Teflon Sheets
2 x Extra Heater Elements
1 x English User Manual
Color Box Size:430x102x175mm
PFS-300 Hand Impulse Plastic Bag Sealer Weight:1.68 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:525x445x360mm
G.W/CTN:17.78Kg
Hand Impulse Plastic Bag Sealer ABS Plastic Shell PFS-Series Table Top Make Heat Press Plastic Film Bag Sealing Machine Operation:
Plug machine into 115v outlet with ground
Press down on handle and verify pilot lamp is lighting or not
According to material thickness and type, regulate dial heating knob starting from position 1 and increasing the amount of sealing time until the poly bag is sealed.
Hold handle down 2-3 seconds after pilot light goes out to allow the seal to congeal.
If too much sealing time is applied the seal will not be perfect.
This unit is not intended to be used as a way to cut and separate poly material. Using the machine in this manner will void all warranties and will cause the teflon and wires to prematurely wear and burn out.
HS CODE:8422303090
Hand Impulse Plastic Bag Sealer ABS Plastic Shell PFS-Series Table Top Make Heat Press Plastic Film Bag Sealing Machine Specification:
| Model | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Max sealing length | 100mm/4 inches/10cm | 150mm/15cm/6 inches | 200mm/8 inches/20cm | 250mm/10 inches/25cm | 300mm/12 inches/30cm | 400mm/16 inches/40cm |
| Sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Max sealing thickness | 0.6mm | 0.6mm | 0.6mm | 0.8mm | 0.8mm | 0.8mm |
| Adjustable heating time | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-2 S |
| Dimensions (LX W X H)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 PCS/Color Box | |||||
| QTY/CTN | 20 PCS | 20 PCS | 10 PCS | 10 PCS | 10 PCS | 10 PCS |
| Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
