Manually Operated Impulse Sealer Sealing Bag Machine PFS-200
Product Details
Make and Sale Manually Operated Impulse Sealer 8 Inch / 200 mm / 20 cm Width Hand Heat Sealing Plastic Bag Machine PFS-200 In Factory From China.Manually Operated Impulse Sealer Plastic ABS Shell PFS-Series Hand Heat Sealing Plastic Bag Machine is ideal for multitude of applications.Makes excellent air and water tight seals on materials listed as Polyethylene,Pliofilm,PVA,Polyurethane,Kel-F,Tivac,Polyvinylchloride,Polyflex,Saran,Po,ypropylene Myla,Nylon Paper and Bag.
Hand Impulse Sealer that provides a perfect sealing solution in order to pack various kinds of plastic bags. With due precision, this sealer is manufactured with the use of quality examined components at our sophisticated manufacturing set-up by our adroit professionals. Furthermore, this Hand Impulse Sealer is made available in numerous technical specifications at marginal rates for our clients.
Manually Operated Impulse Sealer Plastic ABS Shell PFS-Series Hand Heat Sealing Plastic Bag Machine is equipped with a plug-in electronic timer which controls the different sealing times needed for different materials and thicknesses. The timer light goes off when the seal is done. It is recommended that the operator hold the seal bar done for a few seconds after the light goes out to ensure time for the seal to cool and set.
Manually Operated Impulse Sealer 8 Inch / 200 mm / 20 cm Width Hand Heat Sealing Plastic Bag Machine Features:
Sealing Length:8 Inch / 200 mm / 20 cm
Width for seal: 2 mm
Heat Time: 0.2 -1.5 s
Max thickness for seal: 0.4 X 2 mm
Width for seal: 2 mm
Heat Time: 0.2 -1.5 s
Max thickness for seal: 0.4 X 2 mm
Can OEM Products
Fast and Reliable Hand Held Sealer!
Easy To Set Up, Use, and Maintain!
Durable Construction - Top Customer Reviews In Its Class!
Impeccable performance
High efficiency
Robust construction
Longer service life
Electricity is used only when the sealing bar is down for safety.
8 different adjustable lengths of sealing time.
Seals a range of materials including polyethylene, mylar, nylon, polypropylene, tyvek, and more.
This series sealer is simple to be activated with the heating time adaptable and appropriate to seal a variety of diverse kinds of plastic films. It initiates working just by switching on the power supply.
CE,RoHS and CCC Certified.
Customize: OEM and ODM available.
Manually Operated Impulse Sealer 8 Inch / 200 mm / 20 cm Width Hand Heat Sealing Plastic Bag Machine Description:-
Model: PFS-200
Color: Light Blue,Green,White or Red
Sealing Length:8 Inch / 200 mm / 20 cm
Width for seal: 2 mm
Heat Time: 0.2 -1.5 s
Max thickness for seal: 0.4 X 2 mm
Source: AC110V / 60Hz or AC220V / 50Hz
Power: 300 W
Dimensions: 33X10X17.2 cm (L X W X H)
Weight: 1.26 Kg - CE and CCC Certified
- Material: Plastic ABS Housing + Aluminum Frame
- These hand-held heat impulse sealers are great for sealing poly tubing and poly bags in 4 inch,6 inch,8 inch,10 inch,12 inch,and 16 inch sealing widths. These plastic bag heat sealers are designed for industrial bag sealing use. Our sealers require no warm-up time and can have an optional built-in cutter for use with poly tubing.
1 X PFS-200 Manually Operated Impulse Sealer
2 X Extra Teflon Sheets
2 X Extra Heater Elements
1 X English User Manual
Color Box Size:33 X 10 X 17.2 cm
PFS-200 Manually Operated Impulse Sealer Weight:1.26 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:51 X 34.5 X 36 cm
G.W/CTN:13.38 Kg
2 X Extra Teflon Sheets
2 X Extra Heater Elements
1 X English User Manual
Color Box Size:33 X 10 X 17.2 cm
PFS-200 Manually Operated Impulse Sealer Weight:1.26 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:51 X 34.5 X 36 cm
G.W/CTN:13.38 Kg
How to use Manually Operated Impulse Sealer Plastic ABS Shell PFS-Series Hand Heat Sealing Plastic Bag Machine:
The operator puts a bag over the sealing feature in a clear process and triggers the device by lowering the upper jaw. To fuse the closed pocket, a short burst of electricity is transmitted via a specially designed heating cable.
After a pre-set time, the procedure stops when the operator removes the bag and starts with another.
Such devices work efficiently and have predictable outcomes. Learning to operate them is easy.
They are also energy-efficient, reliable, and robust, in addition to their ease of use.
HS CODE:8422303090
Manually Operated Impulse Sealer Plastic ABS Shell PFS-Series Hand Heat Sealing Plastic Bag Machine Specification:
| Model | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Max sealing length |
100mm (4 inch) |
150mm (6 inch) |
200mm (8 inch) |
250mm (10 inch) |
300mm (12 inch) |
400mm (16 inch) |
| Max sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Max sealing thickness | 0.6mm | 0.6mm | 0.6mm | 0.8mm | 0.8mm | 0.8mm |
| Adjustable heating time | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-2 S |
| Dimensions (LX W X H)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 PCS/Color Box | |||||
| QTY/CTN | 20 PCS | 20 PCS | 10 PCS | 10 PCS | 10 PCS | 10 PCS |
| Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
