Impulse Sealers Plastic Tubing Heat Sealing Machines PFS-300
Sale Impulse Sealers For Plastic Tubing Heat Sealing Machines PFS-300 From Factory In China.Impulse Sealers Plastic ABS Body PFS-Series For Plastic Tubing Heat Sealing Machines Can create those perfectly sealed plastic bags that keep food fresh, prevent leaks, or protect delicate items,The secret lies in impulse sealers.The versatile and efficient packaging machines designed to seal plastic bags with precision.
Impulse sealers use a quick burst of electricity to heat a metal wire, which melts the plastic layers together and forms a strong, tamper-proof seal. Unlike constant heat sealers, they only generate heat when activated. This makes them energy-efficient and safe to use. Once sealed, the plastic won’t open unless it’s cut, ensuring a tight, professional finish. These machines are easy to operate. But proper training is essential to achieve consistent, high-quality results. Impulse sealers are powerful packaging tools that secure and airtight seal the plastic materials like poly bags and stand-up pouches.Whether you’re preserving food, protecting products, or ensuring leak-proof packaging, these machines make the job effortless.
Max Sealing Width: 2mm
Sealing Thickness: 0.01-0.8mm
Heating time: 0.2-1.5 s
Can Make OEM Products
Impulse Sealers For Plastic Tubing Heat Sealing Machines PFS-300 Features:
- Model: PFS-300
Max Sealing Width: 2mm
Sealing Thickness: 0.01-0.8mm
Heating time: 0.2-1.5 s
Can Make OEM Products
Impulse Sealers Plastic ABS Body PFS-Series For Plastic Tubing Heat Sealing Machines are particularly suitable for thermoplastics as these melt when exposed to heat and form a permanent bond after cooling. Frequently used materials are:
Polyethylene (PE): often used in packaging and films as it is both flexible and robust.
Polypropylene (PP): ideal for medical and chemical applications thanks to its high temperature resistance.
Polyvinyl chloride (PVC): often used in technical applications as it is highly resistant.
Polyester (PET): for film packaging and other applications that require transparency and stability.
Special films: laminated or coated materials, such as aluminum laminated films, metalized films, high barrier films, paper-based films used in demanding areas such as the food or pharmaceutical industries.
Biofilm: an environmentally friendly alternative that is biodegradable and increasingly used for sustainable packaging.
Cellulose-based films: made from natural polymer. The main component is plant cell walls; these films are ideal for applications where sustainability is a priority.
Mono-materials: consist of one material, as opposed to multi-layered or a mix of several different materials.
Post-Consumer Recycled (PCR): recycled materials that are recovered from end-user waste, reprocessed and reused to manufacture new products or packaging in order to conserve resources and reduce environmental impact.
Impulse Sealers For Plastic Tubing Heat Sealing Machines PFS-300 Specifications:
2 X Extra Teflon Sheets
2 X Extra Heater Elements
1 X English User Manual
Color Box Size:430X102X175mm
PFS-300 Impulse Heat Sealer Weight: 1.68 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:525X445X360mm
G.W/CTN:17.78Kg
-
Model: PFS-300
Color:Gray,Black,Blue,White
Sealing Length: 30cm / 300mm / 12 InchesMax Sealing Width: 2mm
Sealing Thickness: 0.01-0.8mm
Heating time:0.2-1.5S
Power:400W
Source: AC110V60Hz or AC220V50Hz
Dimension: 430X102X175mm (L X W X H)
Item Weight: 1.68 kg - SAA approval plug: EU plug/AU plug
- CE Certified
-
Impulse sealing is characterized by particularly fast process times, as the heating and cooling phases are very short. This means that a large number of solid weld seams can be produced in a short time (due to the direct cooling phase of the seam area after the welding process), which significantly increases productivity.Thanks to the exact control of temperature and pressure, a uniform and high-quality weld seam is guaranteed. This is particularly important in areas where high demands are placed on the tightness and strength of the joint, for example, in the medical and food industries. The heat sensitivity of the material also plays a decisive role in this regard: mono-material films, especially those made of plastics such as polyethylene (PE) or polypropylene (PP), often have a narrow temperature range in which they can be welded without being damaged (e.g. by burning or shrinking).The targeted heat effect is limited to the weld seam and prevents the packaged goods from being affected. This is particularly advantageous for sensitive or thin materials, as damage or deformation can be avoided.Versatility: The contour of the tools can be individually adapted. When it comes to small heating elements with a diameter of 15 mm for heating bonding points to welding thick materials or producing separating, peel and flat seams, impulse sealing offers flexible solutions.
Impulse Sealers For Plastic Tubing Heat Sealing Machines PFS-300 Package Included:
2 X Extra Teflon Sheets
2 X Extra Heater Elements
1 X English User Manual
Color Box Size:430X102X175mm
PFS-300 Impulse Heat Sealer Weight: 1.68 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:525X445X360mm
G.W/CTN:17.78Kg
HS CODE:8422303090
Impulse Sealers Plastic ABS Body PFS-Series For Plastic Tubing Heat Sealing Machines Specification:
| Model. | PFS-100 | PFS-150 | PFS -200 | PFS -250 | PFS-300 | PFS-400 |
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Max.sealing length |
100mm (4 Inch) |
150mm (6 Inch) |
200mm (8 Inch) |
250mm (10 Inch) |
300mm (12 Inch) |
400mm (16 Inch) |
| Max.sealing thickness | 0.3mm | |||||
| Sealing width | 2mm | 3mm | ||||
| Heating time | 0.2-1.5s | 0.2-2s | ||||
| Dimensions (L x W x H) Cm | 24.5X9.5X17 | 29.5X9.5X18 | 33X10X17.2 | 38X10.2X18.3 | 43X10.2X17.5 | 57.5X10.5X19 |
| Weight(Kgs) | 1.06 | 1.24 | 1.26 | 1.58 | 1.68 | 2.82 |
| Package | 1 Pcs/Color Box | |||||
| QTY/CTN(Pcs) | 20 | 10 | ||||
| Carton Size(cm) | 49X25.5X64 | 52.5X29.5X65.5 | 51X34.5X36 | 53.5X39.5X36 | 52.5X44.5X36 | 59X55.5X39 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
