Hand Impulse Heating Plastic Bag Film Sealing Sealer PFS-200
Food and non-food applications
Commercial and home use
Seals a wide variety of bags & films
Durable, anti-corrosion and moisture-proof
A sound as a reminder after the sealing is completed
Increase the cooling fan to reduce the heating speed
Intelligently detect the temperature of the heating element and the housing case
8-speed adjustment，No warm up time needed
Adjustable heat controls
Timer for sealing control
Compact and portable
Aluminum alloy pressure rod
Longer and bolder power cord
Seals all kinds of plastic
Compact size and light weight, easy to carry and use.
Heating up quickly, almost no preheating time.
Food and non-food applications, for both commercial and home use.
Seal a wide range of bags and films with a maximum seal width of 20cm.
8-grades adjustable thermal temperature control.
Automatic power-off , the machine is plugged into the power supply, the default power-off state, when the operation is used, the sealing machine is powered on and heated to complete the sealing.
Power: 300W
Max Length for seal: 200mm
Width for seal: 2mm
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Single phase variable temperature control
CE and CCC Certified
Inexpensive and Portable Sealing 8/200 mm/8 inch/20 cm Length With Sealing 2.0 mm Width Electric Flat Heat Wire Poly Tubing Film Heat Sealing Machine PFS-200 Hand Impulse Heating Plastic Bag Film Sealing Sealer Description:
Fast Heating Power-Saving Impulse Sealer Machine.
Keep sealing edges clean - prolong the life of the heating element.
Clean with a dry cloth or alcohol.
Damage to the sealing rubber will lessen the effectiveness of the sealer.
For PE/PP bags used to package food products
Impulse sealing for power saving
Precision electric control circuit
Adjustable Temperature
Secure Tight Seal
Sealing Length: 8"/200 mm/8 inch/20 cm Length
Source: 110V / 60Hz,220V/50Hz
Power: 300W
Max Length for seal: 200mm
Width for seal: 2mm
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Single phase variable temperature control
CE and CCC Certified
Suitable for: PE/PP Bags
Impluse Sealing for: Power-saving
Circuit: Precision Electronic Control
Color: Blue as pictures shown
Dimensions: 33X10X17.2 cm (L x W x H)
Weight: 1260g
Size: 8"/200 mm/8 inch/20 cm
Plug Type: US Standard
Material: Plastic ABS
Inexpensive and Portable Sealing 8/200 mm/8 inch/20 cm Length With Sealing 2.0 mm Width Electric Flat Heat Wire Poly Tubing Film Heat Sealing Machine PFS-200 Hand Impulse Heating Plastic Bag Film Sealing Sealer Packing List:
2x 8"/200 mm/8 inch/20 cm Long Extra Spare Teflon sheet
2x 8"/200 mm/8 inch/20 cm Long Extra Spare Sealing 2.0 mm Width Electric Flat Heat Wire
1x English User Manual
1 PCS/Color Box
Color box Size:33X10X17.2 cm
PFS-200 Poly Tubing Film Heat Sealing Machine Hand Impulse Heating Plastic Bag Film Sealing Sealer Weight: 1.26Kg
10 PCS/CTN
Carton Size:51X34.5X36 cm
G.W/CTN:13.38Kg
Using Inexpensive and Portable Sealing 2.0 mm Width Electric Flat Heat Wire Poly Tubing Film Heat Sealing Machine PFS Series Hand Impulse Heating Plastic Bag Film Sealing Sealer Instructions:
1. Just connect the power cable to your socket,adjust the heating time according to Sealing Thickness of the material.Put the plastic bag on it,then press the handle,the led indicator light will be on,the machine will control the heating time itself.When the LED indicator light is off, the power automatically disconnect.Release the handle after 1-2 seconds,then it's finished sealing.
2.The Led indicator Light is on only when the machine is sealing,it's not on if you just connect it to socket.
3.If damage appears when it's sealing,that's because the heating time is too long,then shorten the heating time by rotating the timer knob with anticlockwise rotation.
4.If Insecure sealing appears,that's because the heating time is too short,then extend the heating time by rotating the timer knob with clockwise rotation
5.If the plastic bag is sticky to machine,that's because the cooling time is not long enough.Please extend the cooling time after the LED light is off,hold longer time to release the handle.
6.If heating time is adjusted,don't do any change when it's sealing or continuous sealing.
7.You can always connect the power cable to the socket,because if it's not sealing,it won't have any Electrcity consumption.
HS CODE:8422303090
Inexpensive and Portable Sealing 2.0 mm Width Electric Flat Heat Wire Poly Tubing Film Heat Sealing Machine PFS Series Hand Impulse Heating Plastic Bag Film Sealing Sealer Specifications:
| Model No. | PFS-100 | PFS-150 | PFS -200 | PFS -250 | PFS-300 | PFS-400 |
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Max sealing length | 100mm | 150mm | 200mm | 250mm | 300mm | 400mm |
| Max sealing thickness | 0.3mm | 0.3mm | 0.3mm | 0.3mm | 0.3mm | 0.3mm |
| Max sealing width | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 3.0mm |
| Heating time | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-2S |
| Dimensions (L x W x H) Cm | 24.5X9.5X17 | 29.5X9.5X18 | 33X10X17.2 | 38X10.2X18.3 | 43X10.2X17.5 | 57.5X10.5X19 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| QTY/CTN | 20PCS | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 49X25.5X64 | 52.5X29.5X65.5 | 51X34.5X36 | 53.5X39.5X36 | 52.5X44.5X36 | 59X55.5X39 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
